730-Ton Cold Chamber Die Casting Machine | SD-730 CH

High-end Intelligent Model

Meter-In, Injection System

Item	Units	SD-730 CH
Die Locking Force	KN	7300
Die Platen Dimensions (HxW)	mm	1230x1230
Space between Tie Bars	mm	852x852
Tie Bar Diameter	mm	160
Die Stroke	mm	660
Die Thickness	mm	350~900
Solenoid Valve for Core	Piece	1/2"x3
Hydraulic Outlet	Set	3/4"x5
Injection Force	KN	550
Plunger Stroke	mm	670
Plunger-Tip Projection Distance	mm	300
Injection Port Position	mm	-175
Dry Shot Speed	M/S	6	7	8
Plunger-tip Diameter	mm	Min.	Sta.	Max.
Plunger-tip Diameter	mm	70	80	90
Maximun Casting Pressure	Mpa	140.5	107.7	85.1
Casting Area	cm²	462 582	604 760	764 962
Actual Shot Weight	Kg	5	6.6	8.3
Ejection Force	KN	300
Ejection Stroke	mm	125
Hydraulic Motor	kw	37
Amount of Hydraulic Fluid	L	800
Amount of Cooling Water for Oil Cooling	L/min	80
Amount of Cooling Water for Die Casting Cooling	L/min	50-90
Machine Weight	ton	30
Machine Size	mm	8046x2335x3413
