580-Ton Cold Chamber Die Casting Machine | SD-580 CH

High-end Intelligent Model

Meter-In, Injection System

Item	Units	SD-580 CH
Die Locking Force	KN	5800
Die Platen Dimensions (HxW)	mm	1090x1180
Space between Tie Bars	mm	750x750
Tie Bar Diameter	mm	150
Die Stroke	mm	560
Die Thickness	mm	350~850
Solenoid Valve for Core	Piece	1/2"x2
Hydraulic Outlet	Set	3/4"x3
Injection Force	KN	506
Plunger Stroke	mm	580
Plunger-Tip Projection Distance	mm	250
Injection Port Position	mm	-175
Dry Shot Speed	M/S	6	7	8
Plunger-tip Diameter	mm	Min.	Sta.	Max.
Plunger-tip Diameter	mm	70	80	90
Maximun Casting Pressure	Mpa	117.7	90	71.1
Casting Area	cm²	416 624	544 816	688 1033
Actual Shot Weight	Kg	4.35	5.68	7.19
Ejection Force	KN	259.7
Ejection Stroke	mm	110
Hydraulic Motor	kw	37
Amount of Hydraulic Fluid	L	700
Amount of Cooling Water for Oil Cooling	L/min	80
Amount of Cooling Water for Die Casting Cooling	L/min	50-90
Machine Weight	ton	23
Machine Size	mm	7590x2065x3345
